Features:
1. Automatic washing setting
2. Onekey recovery
3. Automatic power on test
4. No dead halt design
5. Manual/automatic temperature compensation
6. Automatic circulating button
7. Integrated memory
8. Automatic identification standard liquid
9. Online numerical correction function
Technical parameters:
1. Display mode: LCD, high light
2. Range of measurement: 0~14.00 pH, -1999~+1999mV, 0~99.9℃
3. Relay control range: 0~14pH
4. Washing time: 1 sec-99 min 59 sec
6. Washing interval: 1-720 min
7. Resolution ratio: 0.01 pH, 0.1mV, 0.1℃
8. Precision: ±0.02pH, ±0.5mV, ±0.3℃
9. Grade: 0.05 level
10. Stability: ±0.01pH/24h
11. Control interface: ON/OFF relay contact
12. Adjustable range: zero ±1.45pH slope 80%~100%
13. pH standard liquid: 6.86/4.00/9.18 7.00/4.00/10.00
14. Relay retardation: 0.01~3.00pH or 0~300mV free adjustment
15. Relay load: MAX 220V AC 5A
16. Signal output load: ≤500Ω
17. Signal input impedance: ≥1×1012Ω
18. Temperature compensation: automatic/manual 0~99.9℃, 25℃ conversion
19. Two groups of signal output: 4~20mA(PH value) 4~20mA(temperature value)
20. Protection grade: IP65
21. Working voltage: AC220V±10% 50/60Hz
22. Size: 96×96×118mm
23. Installation: embedded installation
24. Weight: about 1Kg
25. Working condition:
① Environment temperature : -5 ~ 55℃, relative humidity≤90℅
②Relative air humidity: ≤90%
③Without strong magnetic-field interference except earth magnetic field
|
